Introduction:

The construction of plucked string instruments - specifically lutes, baroque guitars, vihuelas, and similar instruments, is an extremely complex process. Given my decades of collaboration with top-tier professional musicians - and the high standards and demands they set - my work has continuously evolved and has now reached a very high level of quality. The manufacturing process of an instrument begins with the careful selection of inhomogeneous tonewood and concludes with the determination of string tension. Every type of wood used for the body and soundboard of an instrument - down to the individual tree trunk and the specific piece of wood taken from it - possesses its own unique, inherent properties. Thanks to my extensive experience working with tonewoods, I ensure that the wood used is brought to its specific, optimal thickness for each individual instrument. To fully bring out the best possiblel acoustic properties of the chosen sound wood. Only by following this approach can one achieve a balanced combination of timbre and volume, consistency across all registers, dynamic range, sound projection, ease of response, and excellent playability.

A central aspect of this working method is the specific distribution of varying material thicknesses across the spruce soundboard. Equally important is the design of the internal baring - the placement and fine-tuning of the dimensions of the individual bars. The wood used for the body is also processed to a specific, appropriate material thickness. In addition to the choice of wood used for the body, the deep of the body also influences the timbre and projection.


I have been working for a very long time with musicians with musicians, and have optimized my instruments for professional and virtuosic use in collaboration with them. In individual consultations, additional customization, optimal playability, and subjective sound tuning have been (and will continue to be) defined in order to implement personal tonal and haptic preferences on the instrument.


My models are an attempt to come as close as possible to the original; at the same time, they are interpretations, for which I access historical and scientific sources (plans, specialist literature, measurements, dendrochronology, photos, X-rays and computer tomography of originals, as well as historical illustrations). During production, I adhere to the respective tradition of construction.


For the body, high-quality, air-dried woods receive special consideration. I seek out and work with woods that have not only a natural structure and color, but also a special grain. It is my aesthetic goal to bring the natural beauty of the wood to the forefront.


Useful Informations:

The sometimes very good acoustic performance of an original instrument cannot be replicated by an exact hand-crafted copy. Plucked instruments are highly complex, tensioned sound bodies with a flat soundboard construction as the central element of sound production from the living, inhomogeneous natural material wood. Compared to those of the replica (even if the wood species is the same), the wood(s) of the original have different chemical, physical mechanical and acoustic properties

Compared to those of the replica (even when the same wood species is use) the wood(s) of the original, in some cases, significantly different chemical, physical, mechanical, and acoustic properties (Density, stiffness, and elasticity vary significantly!). For these reasons, a replica of a high-quality original instrument lacking the exact same characteristics cannot achieve the same level of sonic performance as the original. To ensure that each instrument can develop its optimal sound, I focus my work on coordinating these individual material properties.

The idea had been under discussion for some time. At the request of two clients, I used old spruce soundboard wood - dating from 1830–50 and sourced from two fortepianos - for two newly built lutes. The lute soundboards obtained from this material differed significantly from new soundboard wood, both in their perceived haptic quality (they were stiffer than new top wood) and in the sound they produced in tapping tests.
Carefully selected, very old wood used for the soundboard of a lute produces a beautifully defined, rather dry tone from the very beginning. However, due to a long period of inactivity - during which the wood was not subjected to any vibrations - it lacks elasticity, which results in limited acoustic projection.
The "breaking-in" period for such wood requires significantly more time and patience than would be the case if new wood were used for the soundboard.

Explanation: Constant vibrations lead to microstructural changes in the material, making the wood used for the soundboard more elastic - and thus more flexible - which in turn allows it to respond better to vibrations and resonance. In instrument making, this physical process is referred to as "breaking in" or "settling in." Musicians often describe this by saying that the instrument “breathes more freely” or sounds “more open.”

Johann Georg Weichenberger

11-courses lute J. Langenwalder 1627/1720 with "swan-neck"

W. J. Lauffensteiner

11-courses lute A. Berr 1699

For both lutes, which have been fitted with an “old” soundboard - including the supporting beam structure - the same individual and complex manufacturing process applies that I described in the introduction at the beginning.


old spruce soundboard wood (1830-50) from two fortepianos

a lute soundboard crafted from this


During the aging process, (spruce) wood undergoes chemical changes, which in turn trigger physical and mechanical alterations.
These include:
- The degradation of hemicellulose leads to reduced stiffness across to the fiber direction, a diminished water-binding capacity, and a lower density.
- the crystallization of cellulose, leading to greater stability and stiffness along the grain (in the direction of the fibers);
- the degradation of lignin, resulting in lower stiffness across the grain (perpendicular to the fibers) and reduced density;
- the crystallization of resins; the resins undergo outgassing, which causes them to become brittle rather than remaining viscous or pliable.

The factors that lead to increased rigidity improve dimensional stability, while flexural strength and elasticity decrease.


Note: If an "old instrument" is not played at all for many years, its molecular chains can revert to a more static, rigid state. In a sense, the instrument "falls asleep," subsequently requiring an intensive process to "awaken" it - or "play it back" into a responsive condition.

The constant vibrations that occur during play act like a micro-massage on the cell structure. Resin crystals are mechanically loosened and "shaken free." The molecular bonds between the wood fibers lose their static rigidity, which reduces the internal resistance of the wood. Furthermore, wood possesses a natural "internal damping" -meaning it absorbs a portion of the kinetic energy -and this damping factor decreases with regular vibration. The wood becomes more elastic: it reacts more quickly when the strings are plucked (improved responsiveness) and vibrates more freely, all without losing its static stability. The highly delicate lute, with up to 26 strings, is subjected to enormous static tension. The soundboard tends to arch, while the internal bracing provides counter-resistance. When this static load is overlaid with dynamic vibrations, the components "settle." Stresses that arose during construction or as a result of the wood drying out are dissipated. The entire system gains greater overall flexibility.

On a personal note:

I have been working professionally with wood and its properties since I was 15. My first five-year apprenticeship included a thorough grounding in woodworking, materials science for wood, static, art history, color- form- and proportion theory. At 22, I began my second apprenticeship as a string and bowed instrument maker. I completed it in 1999 with a master craftsman's certificate. Even during my training, I felt a great interest in the huge diversity of Renaissance and Baroque plucked instruments, their high-end craftsmanship and, in particular, their overtone-rich soundworlds. This fascination remains unbroken for me to this day. My specialization in new construction in this area took place after I received my master craftsman's certificate in 1999.

Theorbo Christoph Koch 1650

(Information about the design and features of my offered instruments can be found in the instrument groups, individual models and the general terms and conditions).


All the instruments I offer are unique. To document the respective optimizations in terms of sound and feel, I have created detailed digital plans of their internal and external structure. They are played by musicians from all over the EU, neighboring countries, the USA, Australia, Israel, and elsewhere. Many of my instruments have been purchased by the following universities and conservatories: mdw Vienna, MUK Vienna, HfMT Cologne, HfM Würzburg, HfM Munich, Freiburg, Mozarteum Salzburg, Kunstuni Graz – and in these institutions, they have been made available to students to practice and perform on.


Releases - Recordings


The recordings selected here consist exclusively of solo performances or small ensembles.


Projects:

From 2013 to 2016, on the initiative of lutenist Hubert Hoffmann, the conservation and documentation of the lutes still in the possession of Kremsmünster Abbey was carried out by restorers Klaus Martius and Sebastian Kirsch (four 11-course lutes, one 13-course lute, one mandora). Dendrochronological investigations were carried out to determine the age of the spruce soundboards.

Within this framework, I was able to produce the most accurate possible reconstruction of the small 11-courses Langenwalder 1627 /Greiml 1678 Baroque lute, using detailed measurements on the opened original, including X-rays. In the second step, I developed a new 11-course model with a "swan neck" and fan-shaped baring under the bridge on the spruce belly common from 1700 onwards.

My project was financed thanks to a grant from the Austria Wirtschaftsservice (aws 2014, two-stage selection process).

Left: My prototype with a "swan neck", a fretboard baroque neck, and fan-shaped baring.
Right: A replica, as exact as possible, of the original bent-neck lute by Jacob Langenwalder in 1627 / rebuilt to 11 courses by Matthias Greimbl in Kremsmünster in 1678.
The original has "Renaissance" baring and a fir wood body. Before the rebuild in 1678, the lute probably had 9 or 10 courses (a small archelute?).


What makes this project special is that these six lutes have been preserved in their original condition. In the last 250 years, they have neither been converted into guitars nor restored multiple times. As a result, the existing wear patterns on the lute soundboard in the area of the bridge allow conclusions to be drawn about the position of the supporting finger of the plucking hand.


Existing wear patterns on the Kremsmünster lutes.

(The lutes of Kremsmünster Abbey, PLV Peißenberg 2020)


In 2018, the Mozarteum Salzburg commissioned several musical instrument makers to produce exact replicas from musical instruments in the Salzburg Museum. In connection with this, and through the mediation of lutenist Hubert Hoffmann, I carried out the measurement of the original 11-courses Baroque lute by A. F. Mayer (1723) – body by Michael Gartner (1524) – as well as the colachon by Johannes Schorn (1688), and made copies that were as accurate as possible using computed tomographys.

Dendrochronological investigations were carried out to determine the age of the spruce soundboards.
The original lute by Michael Gartner (1524) probably had 5 or 6-courses. As part of the project, the Mozarteum Salzburg also commissioned the construction of a replica of Michael Gartner's 6-courses tenor Renaissance lute. Various historical depictions served as the basis for the external design.

Original lute by Michael Gartner (the body ist from 1524 and one of the oldest), rebuilt by A. F. Mayer (1723) in a 11 courses d-minor lute, Salzburg Museum (MI 1087)


Information:

The acoustic tuning of plucked instruments made from the inhomogeneous natural material wood, especially the soundboard including the bar construction, is a very individual, diverse and complex art and requires the senses of sight, hearing and touch. The use of acoustic measurement methods (modal- / vibration patterns analysis), which is particularly popular in bowed string instrument making, is an attempt to produce the most accurate possible acoustic "(sound-) copy" of a generally highly rated original instruments. The copy is based on the already precisely measured acoustic reference values of the originals (e.g. Stradivari, Guarneri, etc.). Crucial to the creation of the copy is the use of woods whose physical and mechanical properties are as similar as possible to those of the original wood (mass, density, speed of sound in the wood). However, the internal stress state of the original body, with or without strings, which also affects the acoustics, cannot be measured. The application of this measurement method in the acoustic tuning setting process is only useful for newly built plucked and bowed string instruments if the aforementioned conditions are met – namely, that generally very well-rated, measured instruments are available as a reference. If no reference instruments exist (no measured original lutes exist), the application of this method is of little help for new construction. To achieve optimal results in newly built plucked instruments in terms of acoustic quality with regard to a balanced mix of timbre and volume, balance of registers, dynamics and carrying power of the tone, easy response and playability, a long-term reciprocal exchange with professional / virtuoso musicians is essential.



On the original instrument, only the age of the soundboard’s wood can be scientifically determined by means of dendrochronological examination (annual ring analysis) (provided that no “old soundboard” has been newly installed). For all other components, it is not possible to determine the exact age, or a chronological classification can only be based on the construction tradition. Due to frequent modifications (lastly in guitars) or later restorations, it is not possible – or only possible to a limited extent – to determine the exact age of individual instrument parts based on construction tradition.

In some instances, lutes and similar instruments on display in museums or similar places can be considered "original" - either in their entirety or in cases where modifications (often made during the instrument's period of active use) have contributed to its preservation. A notable example of this is the lute collection at Kremsmünster Abbey. In other cases, however, an instrument may be a composite object- consisting of a mixture of "new" and "old" components or fragments, potentially originating from different instrument makers - or it may exhibit alterations made long after its original period of use. Simply observing an instrument on display allows only for speculation regarding its authenticity - or the authenticity of individual visible parts. Without a dendrochronological analysis of the wood used for the soundboard, or access to documentation and restoration reports, any conclusions drawn about an instrument's originality-the dating remain of limited validity.


Development history:

In our modern day, lutes and violins are mostly built in one-person workshops. During the heyday of the lute, instruments were produced in very large numbers using a division of labor. Italian lute makers' workshops processed semi-finished parts that were transported to Italy from the northern edge of the Alps, among other places (excerpt: Füssener Lauten und Geigenbau. Hofmeister Musikverlag, 2017, pp. 95-96). The estates of famous lute makers list the sheer quantity of semi-finished and finished parts, as well as finished lutes. Laux Maler (1552, Bologna) mentions 1,100 lutes, 1,354 soundboards (1,154 of which already had rosettes and inlays). Moise and Magno Tiefenbrucker (1581, Venice) are said to have had 335 lutes, 8 guitars, 150 lute bodies, 60 unfinished lutes, stored semi-finished products, 15,200 yew wood ribs, 2,000 soundboards, 300 bridges, 600 necks, and 160 pegs. Caspar Frei (1627, Bologna) had 522 lutes and chitarrones, several hundred guitars, and 400 soundboards.


The lute has been part of the canon of instruments of the upper class since the 15th century. With its peak in the Renaissance as the queen of instruments. It was seen as a status symbol in aristocratic society and had high monetary and symbolic value. Comparable to the high reputation and value of the instruments of the violin family and the piano in our bourgeois society. According to historical sources, the cost of acquiring and maintaining lutes over the same period of time was many times higher than that of bowed string instruments from the violin family. The lutenist Silvius Leopold Weiss received as much annual salary as the entire Dresden court orchestra combined.


Musical instruments are primarily utilitarian objects intended for making music and can also be elaborately crafted. Due to changes in musical aesthetics, many plucked instruments lost their utilitarian value and disappeared from the Middle Ages through the Renaissance to the Baroque period. A possible redesign ensured their continued use (see Lutes-read more-Transformations). As a result of the fundamental stylistic shift towards Classicism, all Baroque plucked string instruments lost their practical value around 1800. As a result, the majority of simple instruments disappeared. The exception to this development are the bowed string instruments of the violin family. They were adapted or rebuilt to reflect the changes, provided the models allowed it, and have been in continuous use to this day. The art handcrafted execution of existing "disused" Baroque plucked instruments guaranteed the necessary attention and promoted their continued existence in private collections and art cabinets at the time. Today, they can be seen in museum collections as exhibits alongside simpler instruments. This has resulted in a quantitatively distorted distribution of simple instruments in favor of elaborately crafted instruments.



The original sound movement began around 1905 in German-speaking countries. The aim is to interpret music from past eras (especially Baroque, Renaissance, and Classical) as it sounded at the time of its creation. Central to this are the use of original instruments (or copies), historical playing techniques, appropriate instrumentation, and knowledge of articulation, ornamentation, and tempi. As a result, previously obsolete original Baroque (stringed) instruments were put back into use, and at the same time their monetary value increased.

The lute instruments, which had completely disappeared from the public music scene around 1800, were necessary for the basso continuo and used in other musical areas, and were gradually reactivated by interested professionell classical guitarists. Due to the scarcity of original lute instruments and their poor condition, replicas of Renaissance and Baroque lute instruments emerged. Since users and manufacturers initially knew little about the original use, playing technique, string tension, sound and musical aesthetics of the eras, they oriented themselves, with few exceptions, towards the known, then current, classical guitar construction ((high weight due to excessive material thickness, excessive string tension). Also, the strings of the modern classical guitar - wounded strings with a silk core (cathedral sound - to long sustain) - were preferred for the basses. Over time, taking original sources into account, a very precise study of the instruments, performance practice and the wonderfully tone-producing gut string material was conducted, and good artificial strings were developed for the lutes.

The modern classical guitar, widely used in our time, and its "sound world" with its 6 individual strings with, its very different playing style - plucking technique, feel, construction - with thicker material thicknesses, its higher string tension, its very different sound characteristics and a much more fundamental sound with a deep timbre (the highest string / pitch is not the thinnest possible), still exerts a great influence on the overtone-rich, double string "sound world" of the lute.

The separation of these two very different "sound worlds" still seems difficult for many after so long time. No instrument of the original sound movement is as frequently subjected to so-called "improvements and renewals" with regard to volume as the lute, with the predictable result of a sound character and playing style similar to a classical guitar, or, in the case of instruments with insufficient material thickness on the body, a predictably thin, static instability and a thin, flat sound similar to a "banjo". In historically informed performance practice, such projects would be completely unthinkable on the bowed instruments used.

Everything is always driven of generating a little more volume. The loss of the instruments' "refined" tonal character is, incomprehensibly to me, readily accepted. Personally, I find these new "innovations" sonically unsuccessful, if not downright boring. I am now firmly convinced that lute instruments should be manufactured within the design scope of their respective, known, acoustically primarily effective, traditional construction methods on the body. With an appropriate string tension that allows the right hand to play close to the bridge, as was historically customary.

With the existing knowledge and skills in lute making and the corresponding playing skills of the musicians, a very good sound can be achieved in the building tradition without any loss of sound. However, it must be accepted that lute instruments (this also applies to guitars), where the strings are struck with the fingers (lower energy transfer), cannot achieve the same volume / sound intensity as instruments played with a bow or large keyboard instruments with a mechanism and metal strings.

This situation has led to problems in the orchestral context since the beginning of the original sound movement, as the performances usually take place in spaces that are (historically speaking) too large for lute instruments and are also usually arranged with a disproportionate instrumentation (e.g. a single "quota" theorbo or arciliuti together with a cast that is too large, possibly with "modern" string instruments strung with gut strings - large cello or other modern instruments). Consequently, for the reasons mentioned above, players of lute instruments in the basso continuo must play so close to or beyond their limits that dynamic sound shaping, let alone a good tone, is not possible. Nevertheless, they are barely perceptible to us listeners.

Basso-Continuo: In the context of historically informed performance practice, a thorough musicological investigation into the joint use?, number?, and sizes? / vocal ranges? (soprano?, alto?, bass?, reentrant theorbo) of lute-like instruments used is still pending. Approximately 60 lute players were employed in Jean-Baptiste Lully's opera Alceste (1674).

The same hearing problem also occurs during solo performances in oversized halls, especially for seats further away. Depending on the requirements, I believe there is now an acceptable solution to this age-old problem: a finely tuned, moderate, sound-technical amplification. Thanks to rapid and continuous technological developments, concert organizers and interested musicians can now produce high-quality results relatively inexpensively with the right equipment and a very good microphone. Appropriate instruction and optimization in this area (also in the sense of music video production for social media) should be integrated into educational programs for musicians.

I can no longer follow these arguments, which are contradictory in several respects: In historically informed performance practice, all kinds of so-called "improvements and renewals", which always bring about a significant change in the sound character, are permissible for lute instruments, provided that a somewhat higher volume is achieved. However, the use of sound-enhancing technology to amplify lute instruments (manufactured in the building tradition) is fundamentally rejected.

The moderate use of this technology (wherever possible and necessary) would largely solve the well-known problems of existing imbalances with less sound loss and would allow all listeners to enjoy the lute instruments used in musical performances acoustically adequately even from more distant places.


Workbench concerts:

I organize up to four concerts a year in my workshop to offer a place that serves as a “testing laboratory” for these occasions, which may even platform the presentation of complete programs.

Performers:

David Bergmüller, Thomas Boysen, André Ferreira, Michael Freimuth, Hubert Hoffmann, Haidl Klaus, Sven Schwanberger, Ensemble Cicchetti Musicali
